BSP Spirax Hills Sight Check 022230The Spirax Sarco Combined sight glass and check valve is designed to give maximum visibility for observation of flow, both of condensate discharged from the system under test and for visual reference when commissioning steam traps fitted with adjustable needle valves or steam locks. It can also be used on other liquid lines where the materials are compatible.
Summary:
- Sight check combined with check valve
- For observing discharges from steam traps
- Compliant with European Pressure Equipment Directive 97/23/EC
Specifications:
Body
Bronze
Discharge Tube
Copper
Ball Check
Stainless Steel
Cover
Brass
Cover Bolts
Steel Zinc Plated
Shake Proof Washer
Steel Zinc Plated
Gasket
Glass Reinforced Graphite Laminate
