Bronze/Lift Check Valve - ART 380
The ART 380 Bronze Lift Check valve is manufactured from robust, high-quality bronze and is fully automatic in the function of preventing back flow into a stream. The disc within the body is lifted off its seat by the high pressure of inlet or upstream steam to allow flow to the outlet or downstream side.
Our Bronze Lift Check valves can be fitted horizontally or vertically and have a pressure rating of 20 bar (3/8 – 2”) and 16 Bar (2 ½-4”).
Summary:
- Screwed BSP Parallel (ISO 228/1)
- Bronze Body
- PTFE Disc
- BS 5154 (BS EN12288)
Specifications:
Body
Bronze
Bonnet
Brass
Pressure Rating
20 Bar rated (3/8-2") 16 Bar Rated (2.5"-4")
Connection Type
Screwed BSP Parallel (ISO 228//1)
Standards
BS5154 (BS EN 12288)
Temperature
-10°C to plus 180°c (3/8 -2") -10°c to 170°C (2.5" to 4")
Disc
PTFE
Disc Holder
Brass
Guide
Brass
